Creating a Kidney: How Stem Cells Might Be Used to Bioengineer a Vital Organ

Difficulty
Time Required Short (2-5 days)
Prerequisites An advanced biology course or equivalent understanding of how cells respond to environmental stimmuli and signaling pathways.
Material Availability Readily available
Cost Very Low (under $20)
Safety No issues

Abstract

The human kidney is the most commonly transplanted organ in the United States, numbering more than 17,000 transplants in 2010 alone! But kidney transplantation technology faces a lot of challenges, including a shortage of kidney donors and the need for recipients to take immunosuppressant drugs to keep their bodies from rejecting a transplanted kidney. In this science project, with the help of bioinformatics databases, you will explore how a kidney could be bioengineered using stem cells, potentially overcoming these problems.

Objective

Use bioinformatics databases to determine the best protein environment for bioengineering a kidney.

Credits

Teisha Rowland, PhD, Science Buddies

Cite This Page

MLA Style

Science Buddies Staff. "Creating a Kidney: How Stem Cells Might Be Used to Bioengineer a Vital Organ" Science Buddies. Science Buddies, 16 Nov. 2013. Web. 22 July 2014 <http://www.sciencebuddies.org/science-fair-projects/project_ideas/BioMed_p013.shtml?from=Blog>

APA Style

Science Buddies Staff. (2013, November 16). Creating a Kidney: How Stem Cells Might Be Used to Bioengineer a Vital Organ. Retrieved July 22, 2014 from http://www.sciencebuddies.org/science-fair-projects/project_ideas/BioMed_p013.shtml?from=Blog

Share your story with Science Buddies!

I did this project I Did This Project! Please log in and let us know how things went.


Last edit date: 2013-11-16

Introduction

The demand for kidney transplants is high, but human donors are limited. And even when transplants are successful, to keep the body from rejecting the transplanted organ, the recipient must take long-term immunosuppressant drugs that can cause a number of undesirable side-effects. Ideally, a recipient should receive a patient-specific kidney, made from the recipient's own cells, which would therefore require neither a donor nor immunosuppressant drugs. But how could such a patient-specific kidney be made?

Bioengineering has had some success at creating and transplanting organs into patients. Bioengineering focuses on how tissues and organs can be made, or engineered, to replace damaged or lost tissues and organs. It is just one part of the larger field of regenerative medicine, a fast-growing field focused on creating ways to replace or heal damaged tissues or organs. In 2008, bioengineers achieved the first successful transplant using an organ engineered with a patient's own stem cells, which are cells that can turn into a number of different cell types and can proliferate (multiply in numbers). Specifically, a patient-specific bronchus (an airway tube that goes to a lung) was bioengineered using the patient's stem cells and a trachea from a cadaver (deceased donor). Some other organs (such as urethras) and tissues have been bioengineered using a patient's cells and a synthetic scaffold. A synthetic scaffold is a structure that can be synthesized and supports the growth of cells. If a synthetic scaffold is used instead of cadaver tissue, it makes donors unnecessary. Watch this video to learn more about some efforts to bioengineer tissues and organs.

Video of Biomedical Regeneration screenshot
This video gives an introduction to research focused on bioengineering tissues and organs at the Wake Forest Institute for Regenerative Medicine.

Overall, efforts to bioengineer entire organs have been limited; bioengineering an organ such as the kidney would be a huge undertaking. The kidney is a complex organ, with approximately 18 different cell types. Instead of bioengineering the entire organ, a more feasible goal may be to bioengineer the kidney's nephrons, the main functional units of the kidney. Every kidney contains approximately 0.5 million to 1 million nephrons, and they filter waste from the blood, expel that waste in the form of urine, and return clean fluid to the bloodstream. Every nephron is made up of two main parts, the renal corpuscle and the renal tubule, as shown in Figure 1 below. The renal corpuscle receives unfiltered blood through the glomerulus and filters it through the Bowman's capsule, which sends the waste liquid to the renal tubule, from which it is sent on to be expelled eventually as urine.

Medical Biotechnology science project Diagram of a kidney nephron
Figure 1. A nephron is made up of two main parts: the renal corpuscle and the renal tubule. In the renal corpuscle, the glomerulus receives unfiltered blood, which is filtered through the Bowman's capsule. From there, the blood goes through the renal tubule (colored blue in this diagram), which consists of the proximal tubule, loop of Henle, and distal tubule. The waste liquid is then transported to the collecting duct, from which it goes to the bladder and is expelled as urine. (Adapted from Yosi I (2007, December 25), Wikimedia.)

While commonly used to bioengineer organs, stem cells come in many varieties and some work better in certain situations than others. Some stem cells have been found in the adult kidney, but they are limited; they are thought to be dormant unless a minor repair is needed, and if the nephrons in an adult human kidney are damaged or lost, it is thought they cannot be regenerated. However, embryonic stem cells (or ESCs) and induced pluripotent stem cells (or iPSCs) have been found able to transform, or differentiate, into different kidney cell types. Human embryonic stem cells (hESCs) are isolated from early-stage embryos that have only about 150 cells. (To read more about hESCs, see the related Project Idea, Taking Short Cuts: How Direct Reprogramming Can Transform One Type of Cell Straight into Another.) Because hESCs are isolated at such an early stage during development, they can multiply and become any cell type in the human body, whether bone, hair, heart, etc. Cells such as hESCs that can give rise to any cell type in the body are referred to as pluripotent (from the Latin words plurimus, mearning "very many," and potens, meaning "having power").

Human induced pluripotent stem cells (hiPSCs) are cells that were mature, adult human cells but that have been "reprogrammed" to behave as hESCs. Consequently, not only are hiPSCs pluripotent, like hESCs, but hiPSCs can also be patient specific. This means that a patient could have some of his or her cells removed, such as skin or blood cells, reprogrammed into hiPSCs, and then have those cells turned into whatever types the patient needs, such as kidney cells for bioengineering a new kidney. Making patient-specific cells like this may avoid some potential complications that can occur with tissue and organ transplants, such as immune rejection, where the recipient's immune system tries to prevent the transplanted organ or tissue from surviving.

Although iPSCs have proved capable of differentiating into different kidney cell types, current techniques are inefficient and have not been thoroughly tested with hiPSCs (they have been used primarily with mouse iPSCs). Specifically, the techniques usually lead to a mixture of cells, not a purified population of a certain kidney cell type, and the techniques are generally slow. How can these techniques be improved? One way is by intelligently altering the cells' growing conditions, also called the cells' microenvironment. In a laboratory, the hiPSCs' microenvironment is defined by two key factors: the liquid the cells are grown in, called the cell media, and the substrate the cells are grown on, which can include other cells called "feeder" cells. Altering these two factors can affect how well the hiPSCs differentiate and what cell type they differentiate into. Nutrients and growth factors (substances the cells need to grow) are supplied to the hiPSCs from their cell media, while the cells grab onto the substrate to stay in place. Watch this video to learn more about how hiPSCs are cultured.

Video of Culturing human induced pluripotent stem cells
This video gives an introduction to how human induced pluripotent stem cells are grown in a laboratory. In this video the cell media is pink and Sravanti Kusuma, the speaker, explains that the substrate the cells grow on are "feeder" cells. (YouTube)

To differentiate hiPSCs into a certain cell type, researchers often try to manipulate the cells' microenvironment so that it mimics what the cell would normally be exposed to in the human body. This means that if you want to make kidney cells, the hiPSC media may include soluble growth factors (or "soluble factors") that the cells might encounter during normal kidney development. Likewise, the substrate on which the hiPSCs are differentiating may be made to mimic the structural part of the microenvironment that the kidney cells would encounter in the human body. The extracellular matrix (ECM) is a mesh-like network of proteins that surrounds cells in the body, giving structural support to the cells and promoting communication among them. Some of the proteins that make up the ECM include laminins, collagens, vitronectin, and fibronectin. To interact with any one of these proteins, the hiPSCs need specific cell receptors on the surface of their cells. Consequently, by looking at which cell receptors certain cells have, such as developing kidney cells, researchers can obtain data on what kinds of ECM proteins these cells need as a substrate.

What microenvironment will be the best one for turning hiPSCs into kidney cells? How can this knowledge be applied to bioengineer patient-specific nephrons, and eventually kidneys? In this bioengineering science project, you will be using online bioinformatics databases (collections of biological data) to explore how researchers select soluble factors and suitable ECM proteins to guide hiPSCs into differentiating into nephron cells, and how this could lead ultimately to bioengineering a kidney.

Terms and Concepts

  • Patient-specific
  • Bioengineering
  • Regenerative medicine
  • Stem cells
  • Synthetic scaffold
  • Nephrons
  • Renal corpuscle
  • Glomerulus
  • Bowman's capsule
  • Renal tubule
  • Differentiate
  • Human embryonic stem cells
  • Pluripotent
  • Human induced pluripotent stem cells
  • Immune rejection
  • Microenvironment
  • Cell media
  • Substrate
  • Growth factors
  • Soluble factors
  • Extracellular matrix (ECM)
  • Cell receptors
  • Bioinformatics
  • In vivo
  • In vitro
  • Signaling pathways
  • Apoptosis
  • Epithelial-to-mesenchymal transition (EMT)
  • Precursor cells
  • Integrins
  • Microarray

Questions

  • What are the two main parts of a kidney's nephron? What are their functions?
  • Why is it ideal to bioengineer organs that are patient-specific?
  • What makes stem cells so useful in bioengineering organs?
  • What is the field of bioinformatics? How can it help researchers find out information without doing experiments in a laboratory setting?

Bibliography

To perform this bioengineering science project, you will need to use these databases:

These resources are good places to start gathering information about stem cells and bioengineering organs:

The 2008 study on the first successful organ transplant bioengineered with a patient's own stem cells:

Information about the soluble factors in Table 1 was taken from these sources (also listed in Table 1):

Materials and Equipment

  • Computer with an Internet connection
  • Lab notebook

Share your story with Science Buddies!

I did this project I Did This Project! Please log in and let us know how things went.

Experimental Procedure

Driving Kidney Cell Differentiation Using Soluble Factors

What soluble factors would be best to use when trying to differentiate human induced pluripotent stem cells (hiPSCs) into kidney cells, specifically the kidney cells of the nephron, the functional unit of the kidney? To differentiate hiPSCs into nephron cells efficiently, the soluble factors that are added to the cell media need to prompt the hiPSCs to turn into nephron cells. A few studies have investigated differentiating iPSCs into nephron cell types, but the techniques are inefficient, resulting in a mixture of cell types with only 60% to 90% being the desired cell type. In this part of the science project, you will decide which soluble factors, and combinations of soluble factors, would be best to test when prompting hiPSCs to turn into different types of nephron cells.

  1. Look at Table 1 below, which summarizes the soluble factors used in key publications of research on turning ESCs or iPSCs into different nephron cell types. Note: Table 1 summarizes this information so you do not need the actual papers, which are not publicly available, to do this bioengineering science project.
    1. What soluble factors did the different researchers add to make either podocytes (cells in the glomerulus) or renal tubule cells? You can look at Figure 1 (in the Introduction in the Background tab) to review the structure of, and different cell types in, the nephron.
      1. For example, two groups of researchers (Kramer et al., 2005, and Ren et al., 2010) were able to make podocyte cells. One of these groups (Kramer et al., 2005) did not report adding any soluble factors, while the other one (Ren et al., 2010) reported adding two different soluble factors, activin A and retinoic acid (RA). Three groups (Kramer et al., 2005; Kobayashi et al., 2005; and Morizane et al., 2009) made renal tubule cells using one, two, or no soluble factors.
      2. Although one research group (Kramer et al., 2005) added no soluble factors, whether their efficiency could be improved by adding soluble factors should be investigated.
      3. In the bottom row of Table 1, where the Dankers et al. research from 2011 is listed, several soluble factors are named that are necessary for embryonic kidney development in the body, also called in vivo. These factors are not known to have been tested on cells grown in a laboratory, or in vitro, but they are likely candidates for prompting hiPSCs to differentiate into some nephron-like cells.
      4. Note: Extensive studies have not yet been published on turning pluripotent stem cells into cells of the Bowman's capsule, and so it is omitted from this bioengineering science project. See the "Variations" below for how you could explore bioengineering this part of the nephron.
    2. Although you do not need the research papers to do this science project, if you want to learn more about a particular paper, click on the link under the "Research Paper" column to see the paper, as an abstract or in its entirety. What can you understand about the paper and its reported findings by reading the abstract?
      1. If you are interested in ways to obtain these papers, you may be able to use the guide Resources for Finding and Accessing Scientific Papers to do so.
      2. If you choose to read the papers, you may also find you need some help from someone experienced with stem cells or bioengineering to help you find out How to Read a Scientific Paper.
Nephron Cell Type Main Supplemented Soluble Factors Research Paper
Renal Corpuscle Cells: Podocytes in the Glomerulus No factors added Kramer et al., 2005
  • Activin A
  • Retinoic acid (RA)
  • Conditioned media**
Ren et al., 2010
Renal Tubule Cells No factors added Kramer et al., 2005
  • Wnt4*
  • hepatocyte growth factor (HGF)
  • Activin A
Kobayashi et al., 2005
Activin A Morizane et al., 2009
Necessary for General Kidney Development
  • Transforming growth factor (TGF) alpha
  • Transforming growth factor (TGF) beta
  • Insulin-like growth factor (IGF)
  • Platelet-derived growth factor (PDGF)
Dankers et al., 2011
Table 1. Different soluble factors have been used in key research on turning ESCs or iPSCs into different nephron cell types. In the bottom row, where the Dankers et al. paper from 2011 is listed, several soluble factors are listed that are necessary for embryonic kidney development in the body.

*Wnt4 was not actually a soluble factor, but was transfected into the cells so that the cells made their own Wnt4. In this bioengineering science project, Wnt4 can still be explored and treated as a soluble factor.

** Conditioned media is made by exposing media to cells so that factors secreted by the cells are collected in the media. In the Ren et al. paper from 2010, conditioned media was made and tested from ureteric buds, which are the structures that develop into the entire kidney, except for the nephrons. For the purposes of this engineering science project, conditioned media can be ignored, but it can be explored in the Variations section below.

  1. Learn more about the soluble factors in Table 1 above by using Millipore's pathway search tool, which searches a database of cellular signaling pathways (biochemical pathways). What are the functions of these different soluble factors? How might they be used to differentiate stem cells into different kidney cell types?
    1. Make a data table in your lab notebook to collect and organize information on the different soluble factors from Table 1. Specifically, make a data table like Table 2 below so that you can fill in the related information on each of the factors.

      Soluble factor Family it belongs to Does it regulate proliferation or apoptosis?* Does it regulate differentiation? Does it regulate development? Does it regulate cell migration? Does it regulate epithelial-to-mesenchymal transition?** What other key functions does it have?
      Activin A
      Retinoic acid
      Wnt4
      Hepatocyte growth factor
      Transforming growth factor alpha
      Transforming growth factor beta
      Insulin-like growth factor
      Platelet-derived growth factor
      Table 2. In your lab notebook, create a data table like this one to collection information on each of the soluble factors.

      *Apoptosis is programmed cell death.

      ** During development, the tubules in the nephron (and many other tissues throughout the body) undergo a process called epithelial-to-mesenchymal transition, or EMT, where one type of tissue (epithelial tissues) differentiates into another type (mesenchymal tissues).

      1. You may be unable to answer all of these questions for all of the soluble factors, but put as much relevant information into your data table as you can as you search Millipore's pathways.
    2. On the Millipore webpage, type in the name of a soluble factor from your data table, in quotations, such as "activin a" as shown in Figure 2 below, circled in yellow. From the "Cellular Process" dropdown menu select "Developmental Signaling," as shown in Figure 2 circled in green. Then click "Search."
      1. When searching for a factor's name, do not use abbreviations. For example, for TGF alpha, search for "transforming growth factor alpha."
      Medical Biotechnology science Screenshot of the Millipore pathway search tool.
      Figure 2. Millipore has a pathway search tool that searches a database of cellular signaling pathways. Search for signaling pathways that a soluble factor is involved in by typing in the name of the soluble factor, in quotations, in the search box, as shown for "activin a" circled in yellow above. Then select "Developmental Signaling" from the "Cellular Process" dropdown menu and click "Search."

    3. This should take you to a webpage of search results similar to Figure 3 below. Look for a result that starts with the word "Development" and has the name of the soluble factor in the title, such as "Development Role of Activin A in cell differentiation and proliferation" circled in red in Figure 3.
      1. Why do you think you should look for results related to development?
      2. You may need to go through a few webpages of results before you find the correct result.
      3. Skip looking up RA and Wnt4 on Millipore and go to step 3 below to look up information for them using the NCBI Gene Database instead.
        • The Millipore pathway search tool has very limited information for these factors, but the NCBI Gene Database has much more.
      4. For TGF alpha, use the search result titled "Development EGFR signaling pathway" and look for where TGF alpha is discussed.
      5. For TGF beta and IGF, the only pathways available are for the receptor of these factors, so use the receptor pathway and make a note of it in your data table.
        • Specifically, for TGF beta, use the result titled "Development TGF-beta receptor signaling"; for IGF, use the result titled "Development IGF-1 receptor signaling."
      Medical Biotechnology science project Screenshot of the Millipore pathway search tool results.
      Figure 3. Searching for a given soluble factor using the Millipore pathway search tool should give several results. Look for a result that starts with the word "Development" and includes the name of the soluble factor in the title, such as the result circled in red above for "Activin A."

    4. Click on a result to be taken to a webpage containing a large amount of information on the soluble factor and its signaling pathway involvement. There should be an image of the signaling pathway on the top of the webpage and text below the image.
    5. Looking at the signaling pathway image, find where the soluble factor is. For example, Activin A is on the top left of the pathway image.
      1. What other factors does your factor of interest directly regulate, and which ones does it more distantly regulate?
      2. Green lines indicate a positive regulation (activation at the end of the arrow) while red lines indicate a negative regulation (repression at the end of the arrow). As you can see, interactions between factors are rarely simple, as the same factor may indirectly both activate and repress another factor.
      3. Clicking on a factor in the image will cause additional information to appear on the left-hand side of the screen.
    6. In the data table in your lab notebook, write down the key functions of the soluble factor that are shown within the blue rectangles on the pathway image. Categorize them according to one of the questions in step 2a above.
      1. Tip: Be sure to look at the entire image. You may need to use the scroll bar on the side of the image to do this.
      2. For example, for Activin A under "Does it regulate proliferation or apoptosis?" write "Yes, inhibits cell growth and proliferation." Under "Does it regulate differentiation?" write "Yes, regulates cell differentiation." Under "What other key functions does it have?" write "Regulates stem cell maintenance and progesterone production."
      3. If you run across terms you are unfamiliar with (such as possibly "progesterone"), you should always look them up and try to figure out how they fit in with what else you know about the soluble factor.
    7. After looking at the signaling map, read the "Pathway Description" below the image and see if you can fill in more information about the soluble factor on your data table.
      1. For example, Activin A is explained as belonging to the TGF-beta family.
      2. When reading the "Pathway Description," focus on information that answers the questions in your data table. A lot of information is not relevant for your data table and you will need to evaluate what information is relevant and what is not for filling in your data table.
    8. Repeat steps 2b to 2g for each of the soluble factors listed in Table 1 (except skip RA and Wnt4, as instructed on step 2c).
  2. In addition to gathering information from Millipore, you can use another database, the NCBI Gene Database, to gather additional information to fill out your data table.
    1. Use the Science Buddies NCBI Gene & SNP Tutorial to help you navigate the NCBI Gene Database.
      1. For your searches, use the abbreviated gene names listed in Table 3 below.
      2. Make sure to choose the top search result that lists your soluble factor name, such as "INHBA," and that it is for humans (Homo sapiens).

      Soluble Factor Abbreviated Gene Name
      Activin A INHBA
      RA RARA
      Wnt4 WNT4
      HGF HGF
      TGF alpha TGFA
      TGF beta TGFB1
      IGF IGF1
      PDGF PDGFA
      Table 3. When searching the NCBI Gene Database, use these abbreviated gene names for the soluble factors. Note: The given abbreviated gene name for RA, "RARA," is actually for a receptor of RA, because humans do not have genes to make RA (humans make RA from vitamin A, and so we have receptors for RA, but we do not have genes to make RA).

    2. What does the database tell you about the soluble factor? Fill in your data table with any additional relevant information from the NCBI Gene database.
  3. After you have filled out your data table of soluble factors using the Millipore and NCBI Gene databases, look at how different and how similar the soluble factors are.
    1. Do many of the soluble factors regulate the same function, such as differentiation? Do any factors regulate three of the same functions? If any two factors regulate three of the same functions, they may act similarly.
  4. Review Table 1 above to see which soluble factors have been used previously in the named studies in certain combinations. Can you substitute any of the factors from a previously used combination with a similar factor, based on your data table?
    1. For example, Wnt4, HGF, and Activin A have been previously used in a combination (Kobayashi et al., 2005). Is there another factor similar to Wnt4 that you could use instead of Wnt4 in this combination? Or is there another factor similar to HGF or Activin A that could be substituted instead?
    2. In your lab notebook, create a data table of the different combinations that could be created based on how similar the soluble factors are.
      1. Make columns listing the "Nephron Cell Type" and "Existing Combinations of Soluble Factors," as listed in Table 1. Then include columns listing the "Substitutions" that could be made for each factor and the "Potential Combinations" that could be made based on the substitutions (as discussed in step 5a for Wnt4, HGF, and Activin A).
  5. Using different combinations of soluble factors may improve upon the current nephron cell differentiation protocols discussed in Table 1. Based on the data table you made in step 5, what would be feasible, new soluble factor combinations to test to turn hiPSCs into podocytes or renal tubule cells? Do you expect some combinations to work better than others? Why? Might some combinations work well to make nephron cells, or nephron precursors (cells that can easily turn into nephron cells), in general?

Using the Extracellular Matrix to Drive Kidney Cell Differentiation

What Extracellular Matrix (ECM) proteins would be best to use when trying to differentiate hiPSCs into nephron cells? The ECM is a mesh-like network of proteins that surrounds cells in the body, giving structural support to the cells and promoting communication among them. To efficiently differentiate hiPSCs into nephron cells, not only do the hiPSCs need the appropriate soluble factors in their media, but the substrate they are grown on can also affect how they differentiate. (The studies summarized in Table 1 did not investigate different substrates, but generated nephron cell types by initially creating cell formations called embryoid bodies, which were cultured by floating them in the media, without touching a substrate, for two to five days. After being in the floating culture, they were cultured on gelatin, which is a standard culture substrate made up of fragments of collagen.) Differentiating hiPSCs on certain ECM proteins may produce nephron cells more efficiently, and this research could be used as the basis for designing synthetic scaffolds on which to grow kidney cells for transplants. To interact with ECM proteins (including laminins, collagens, vitronectin, fibronectin, and more), the hiPSCs need specific cell receptors on the surface of their cells. In this part of the science project, you will examine which cell receptors, called integrins, are made by kidney cells during development.

  1. Table 4 below lists integrins and the ECM proteins they bind.
    1. Integrins are heterodimers, meaning they are made up of two different subunits, specifically an alpha and a beta subunit. Only certain alpha and beta subunits can combine. The combination determines what ECM proteins they can bind.
    2. Note: Not all integrin subunits are listed in Table 4. Table 4 includes integrin subunits that have data in the Amazonia! database and that form integrin heterodimers with well-established information on the ECM proteins they bind. Also, the integrin heterodimers in Table 4 may bind additional ECM proteins that are not listed.
α Integrin Subunits β Integrin Subunits ECM Proteins They Bind
α2 β1 Laminin-111, Laminin-211, Collagen I, Collagen IV
α3 β1 Laminin-332, Laminin-511, Laminin-521, Collagen IV, Fibronectin
α5 β1 Fibronectin, Fibrinogen
α6 β1 Laminin-111, Laminin-211, Laminin-221, Laminin-332, Laminin-511, Laminin-521
β4 Laminins-332, Laminin-511
α7 β1 Laminin-111, Laminin-211, Laminin-221
α8 β1 Fibronectin, Vitronectin
α10 β1 Collagen I, Collagen IV
αV β1 Vitronectin, Fibronectin, Fibrinogen
β5 Vitronectin
β8 Vitronectin, Fibronectin, Collagen IV, Laminin-111
Table 4. This table shows integrin heterodimers and the main ECM proteins they bind.
  1. In your lab notebook, create a data table with a column called "Integrin Subunits" and list each of the integrin subunits in it (all alpha and beta subunits listed in Table 4), with one row for each subunit. Make three additional columns labeled "Expression in Embryonic Kidney" and one more column labeled "Average Expression in Embryonic Kidney." You will be filling in this data table in the following steps.
  2. Learn about the expression of certain integrin subunits by using Amazonia!, a database of microarray data. A microarray is a tool that enables researchers to look at a certain group of cells or tissues and see what genes are being expressed.
    1. At the bottom of the main Amazonia! webpage, there is a search box next to where it says "QuickStart: Explore the expression profile of any gene." In the search box enter the name of one of the integrin subunits from Table 4 above and click "Go!"
      1. For alpha subunits, enter "ITGA" followed by the number. For example, for α5 enter ITGA5. (For integrin αV, use ITGAV.)
      2. For beta subunits, enter "ITGB" followed by the number.
    2. This will take you to a search results webpage, which lists the "Result(s) for Gene & Aliases," or it will take you directly to a webpage with microarray data on the integrin subunit, such as shown in Figure 4 below for the integrin α5 subunit.
      1. If you see "Result(s) for Gene & Aliases," click on the blue link for the subunit you are investigating, which should take you to a webpage similar to Figure 4 below.
      Medical Biotechnology science project Screenshot of the Amazonia database website
      Figure 4. Searching for a specific integrin subunit on Amazonia! should take you to a webpage with microarray data, similar to this one for the integrin α5 subunit.

    3. On the webpage with microarray data for the integrin subunit, scroll down to the section titled "Embryonic and adult normal tissues," as shown in Figure 5 below.
      Medical Biotechnology science project Screenshot of the Amazonia database website
      Figure 5. Scroll down to the "Embryonic and adult normal tissues" section.

    4. The graph shows the expression of the integrin subunit in different cell types. For this science project, you will focus on the expression of the integrin subunit only in kidney cells.
      1. If you are interested in looking at the expression of the integrin subunit in different cell types, you can click on the graph image to enlarge it. On the x-axis cell types are listed. For every cell type, the levels of gene expression (labeled "microarray signal") are shown on the y-axis. (Tip: "Kidney" samples are on the right half of the graph.)
    5. Click on the symbol of the magnifying glass, just under and to the right of the "Embryonic and adult normal tissues" graph (circled in red in Figure 7 above). This will open another window with all of the numerical data from the graph you were just looking at.
      1. Under the "SAMPLES" column find the kidney samples, of which there should be three, as shown in Figure 6 below. (Note: You can use Ctrl+F to find a word or specified text, such as "kidney," on a webpage.)
      2. In your lab notebook in the data table you created in step 2 of this section, in the three columns labeled "Expression in Embryonic Kidney" fill in the "Signal" for the three kidney samples.
      3. Calculate the average of the "Signal" for the three kidney samples (shown in Figure 6 below). For example, the average for the integrin α5 subunit is 69.8. Add this to your data table under "Average Expression in Embryonic Kidney."
      Medical Biotechnology science project Screenshot of the Amazonia database website numerical data
      Figure 6. Clicking on the magnifying glass circled in red in Figure 7 should pop up a data table with all of the numerical data from the graph. This image shows the part of the data table containing information from kidney samples.

    6. Repeat steps 3a to 3e for all integrin subunits in Table 4.
      1. If there are multiple "Embryonic and adult normal tissues" graphs, just use data from the first one.
      2. This should make your data table full.
  3. Looking at your data table, which integrin subunits are most highly expressed, or have the highest values, in the kidney cells?
    1. Set an expression level threshold that results in a list of several "highly expressed" integrin subunits, such as subunits that have average expression levels over 100.
  4. Go back to Table 4 and either print out or copy it in to your lab notebook. Highlight, or mark in some other way, the alpha and beta integrin subunits that you determined to be highly expressed, and the integrin heterodimers that are highly expressed in both their alpha and beta integrin subunits.
  5. Which ECM proteins are bound by the highly expressed integrins? Which ECM proteins are bound by multiple highly expressed integrins? On Table 4 mark which ECM proteins are bound by at least two highly expressed integrins.
  6. Are the marked ECM proteins also highly expressed in the kidney during development? If so, this may make them even better candidates to use in bioengineering a kidney.
    1. Repeat step 3 but this time use the ECM proteins you marked in step 6 instead of integrin subunits.
      1. Use Table 5 below to help you search for the correct ECM protein names on the Amazonia! site. Like integrins, some ECM proteins are also made up of multiple subunits that you will want to investigate.

      ECM Protein(s) Name(s) to Search For
      Laminins
      • Laminins are made up of three subunits, an alpha, beta, and gamma, which are listed in order in their names in Table 4. For example, Laminin-521 is made up of an alpha 5, beta 2, and gamma 1 subunit.
      • For alpha subunits, search for "LAMA" followed by the number. For example, for alpha 5 you would search for "LAMA5."
      • For beta subunits, search for "LAMB" followed by the number.
      • For gamma subunits, search for "LAMC" followed by the number.
      Collagens
      • Collagens are made up of alpha subunits. For these subunits, search for "COL" followed by the number of the collagen and then the specific subunit.
      • Collagen I is made up of alpha 1 and 2 subunits. For these subunits, search for "COL1A1" and "COL1A2," respectively.
      • Collagen IV is made up of alpha 1, 2, 3, 4, 5, and 6 subunits. For these subunits, search for "COL4A1," COL4A2," etc.
      Vitronectin Search for "VTN"
      Fibronectin Search for "FN1"
      Table 5. When searching the NCBI Gene Database, use these abbreviated gene names for the soluble factors. Note: The given abbreviated gene name for RA, "RARA," is actually for a receptor of RA because humans do not produce RA (as noted in the explanation for Table 3 above).

    2. In the data table you made in step 6, underline or highlight which ECM proteins are also highly expressed.

Creating the Right Microenvironment to Make a Kidney

Now that you have determined the ideal media conditions to test and the ideal substrates to grow the cells on, in this part of the science project you will be pulling your results together to create the overall best conditions for bioengineering a kidney, starting with a nephron.

  1. Based on your findings, what would you hypothesize to be the best soluble factors and ECM proteins to use for differentiating hiPSCs into certain nephron cell types?
    1. Review the data tables you made in "Driving Kidney Cell Differentiation Using Soluble Factors" in step 5 and in "Using the Extracellular Matrix to Drive Kidney Cell Differentiation" in step 6.
    2. Make a new data table that combines the results from these data tables. Specifically, have one column listing "Nephron Cell Type" (as listed in Table 1), one listing "Potential Combinations of Soluble Factors," and one listing "Potential ECM Proteins."
      1. Because the ECM proteins you selected were for the kidney as a whole, and not specific kidney cell types, you may want to test the same ECM proteins for all of the different nephron cell types. You can test ECM proteins individually or in combinations.
    3. What results would you expect from your experimental plan? What problems do you anticipate, and how might you be able to solve them? Why might some conditions be more efficient than others?
  2. Based on your findings, what do you hypothesize would be the best overall conditions in which to bioengineer a nephron or an entire kidney?
    1. If you could make a substrate or a kind of "skeleton" to grow the organ on, what ECM proteins should be used to coat it? Why do you think some would be better than others?

Share your story with Science Buddies!

I did this project I Did This Project! Please log in and let us know how things went.


Variations

  • When this project was written, scientific papers had not been published on differentiating pluripotent stem cells into Bowman's capsule cells, an essential type of nephron cell. Try doing a literature search for recent papers that have described this, investigate what soluble factors they used, and then repeat this project using your findings. For help searching the literature, read the guide to Resources for Finding and Accessing Scientific Papers. You may also find you need some help from someone experienced with stem cells to understand How to Read a Scientific Paper.
  • This science project focused on bioengineering a kidney, but many other organs would make good targets for bioengineering efforts. Pick a different organ that is needed for transplants and repeat this project. To find what soluble factors researchers have tested, as shown in Table 1, you may need to search the literature, as described in the first variation.
  • During development, cells that are next to each other, or neighboring cells, influence the differentiation of each other by secreting soluble factors and ECM proteins. This is why in Table 1 a study used conditioned media. (A definition of conditioned media is given immediately following Table 1.) Design a method for culturing hiPSCs with cells that would be neighboring kidney cells during development, aiming to differentiate hiPSCs into kidney cells. How is this approach similar to or different from the one used in this science project, and how do you think one would be better than the other? Could the methods be used in combination?
  • ECM proteins can be used to differentiate hiPSCs, but these proteins are usually isolated from other animals, such as mice and rats. Because our bodies' immune systems may reject foreign proteins, kidneys bioengineered with proteins from mice or rats may be rejected after transplant. An alternative is to use peptides, which are short amino acid sequences in the ECM proteins that are shown to have functional activity. These short sequences can be synthesized in a laboratory, so they are not from mice or rats, and some may be able to interact with cells just as the normal-length protein does. You can learn more about ECM protein peptides and conduct a literature search, as described in the first variation, to find out what ECM peptides may work well for developing a synthetic scaffold for bioengineering a kidney. This can be based on the ECM proteins you selected in "Using the Extracellular Matrix to Drive Kidney Cell Differentiation" in step 6. ECM peptides can be specific for an ECM protein or common among many ECM proteins.

Share your story with Science Buddies!

I did this project I Did This Project! Please log in and let us know how things went.

Ask an Expert

The Ask an Expert Forum is intended to be a place where students can go to find answers to science questions that they have been unable to find using other resources. If you have specific questions about your science fair project or science fair, our team of volunteer scientists can help. Our Experts won't do the work for you, but they will make suggestions, offer guidance, and help you troubleshoot.

Ask an Expert

Related Links

If you like this project, you might enjoy exploring these related careers:

female biologist plotting animal range data on computer

Biologist

Life is all around you in beauty, abundance, and complexity. Biologists are the scientists who study life in all its forms and try to understand fundamental life processes, and how life relates to its environment. They answer basic questions, like how do fireflies create light? Why do grunion fish lay their eggs based on the moon and tides? What genes control deafness? Why don't cancer cells die? How do plants respond to ultraviolet light? Beyond basic research, biologists might also apply their research and create new biotechnology. There are endless discoveries waiting to be found in the field of biology! Read more
female doctor talking to elderly patient

Physician

Physicians work to ease physical and mental suffering due to injury and disease. They diagnose medical conditions and then prescribe or administer appropriate treatments. Physicians also seek to prevent medical problems in their patients by advising preventative care. Ultimately, physicians try to help people live and feel better at every age. Read more
NASA material scientist

Materials Scientist and Engineer

What makes it possible to create high-technology objects like computers and sports gear? It's the materials inside those products. Materials scientists and engineers develop materials, like metals, ceramics, polymers, and composites, that other engineers need for their designs. Materials scientists and engineers think atomically (meaning they understand things at the nanoscale level), but they design microscopically (at the level of a microscope), and their materials are used macroscopically (at the level the eye can see). From heat shields in space, prosthetic limbs, semiconductors, and sunscreens to snowboards, race cars, hard drives, and baking dishes, materials scientists and engineers make the materials that make life better. Read more
bioinformatics scientist evaluating microarray data

Bioinformatics Scientist

The human body can be viewed as a machine made up of complex processes. Scientists are working on figuring out how these processes work and on sequencing and correlating the sections of the genome that correspond to the individual processes. (The genome is an organism's complete set of genetic material.) In the course of doing so, they generate large amounts of data. So large, in fact, that to make sense of it, the data must be organized into databases and labeled. This is where bioinformatics scientists step in. They design databases and develop algorithms for processing and analyzing genomic and other biological information. These scientists work at the crossroads of biology and computer science. Read more

Looking for more science fun?

Try one of our science activities for quick, anytime science explorations. The perfect thing to liven up a rainy day, school vacation, or moment of boredom.

Find an Activity
