What is the Woolly Mammoth's Closest Living Relative?

Difficulty
Time Required Short (2-5 days)
Prerequisites You should be familiar with basic biological concepts, including DNA, proteins, and mutations.
Material Availability Must have access to the Internet.
Cost Very Low (under $20)
Safety No issues

Abstract

Woolly mammoths shook the ground of ice-age tundras for millennia, living next to saber tooth tigers and prehistoric man. Although they have been extinct for thousands of years, scientists continue to learn more and more about this mighty animal. Some of the most exciting new research is being produced by looking at DNA extracted from the hair and bones of woolly mammoths entombed in ice. In this genomics science fair project, you will use bioinformatics tools to determine the woolly mammoth's closest relative. You will also estimate the rate at which the woolly mammoth’s DNA accumulated mutations.

Objective

The objective of this genomics science fair project is to use the BLAST bioinformatics tool to identify the closest living relative of the extinct woolly mammoth. You will also estimate the mutation rate in the woolly mammoth’s mitochondrial DNA.

Credits

David Whyte, PhD, Science Buddies

Cite This Page

MLA Style

Science Buddies Staff. "What is the Woolly Mammoth's Closest Living Relative?" Science Buddies. Science Buddies, 22 Feb. 2013. Web. 31 July 2014 <http://www.sciencebuddies.org/science-fair-projects/project_ideas/Genom_p016.shtml>

APA Style

Science Buddies Staff. (2013, February 22). What is the Woolly Mammoth's Closest Living Relative?. Retrieved July 31, 2014 from http://www.sciencebuddies.org/science-fair-projects/project_ideas/Genom_p016.shtml

Share your story with Science Buddies!

I did this project I Did This Project! Please log in and let us know how things went.


Last edit date: 2013-02-22

Introduction

The application of molecular analysis techniques to samples retrieved from the hair and bone of extinct animals has generated excitement among paleobiologists and other scientists. Our understanding of the woolly mammoth, for example, which used to be based on fossils and comparison with modern elephants, has been enriched by analysis of its DNA.

Woolly mammoths (scientific name: Mammuthus primigenius) are extinct elephant-like animals that roamed Earth until about 10,000 years ago, when scientists believe they became extinct due to warming weather, human hunters, disease, or some combination of these factors.

Woolly mammoth
Figure 1. The woolly mammoth at the Royal BC Museum, Victoria, British Columbia. (Wikipedia, 2008.)

There are believed to be millions of mammoths buried in Siberia's permafrost. Only about 100 specimens have been uncovered in the sparsely populated countryside, but some of them have been remarkably well preserved. In 1997, an entire mummified woolly mammoth was found in Siberian ice! It was transferred in October 1999 to a frigid, underground cave where it will be carefully studied. Scientists hope to clone this remarkable specimen.

Mammoths are classified in the order Proboscidae, which includes mammoths, modern Asian elephants and African elephants, and mastodons. In the past few years, scientists have successfully isolated mitochondrial DNA from the hair and bones of mammoths and mastodons. A study by Nadin Rohland, from the Max Planck Institute for Evolutionary Anthropology in Germany, and his colleagues, demonstrates the power of genetic data to clarify interrelationships. The researchers used the DNA sequence information from a mastodon tooth to estimate that the time of divergence of mastodons occurred about 27 million years ago. African elephants diverged from Asian elephants and mammoths about 7.6 million years ago. The divergence between mammoths and Asian elephants was estimated to have taken place about 6.7 million years ago. See Figure 2.

Proboscidean tree
Figure 2. Phylogeny and divergence times for the four proboscidean species. Phylogenetic trees are like family trees: individuals, or species in this case, are grouped together based on shared ancestry. The image on each of the "branches" is a representation of the animal's tooth. "MY" stands for million years. (Rohland, et al., 2007.)

The analysis of mitochondrial DNA is a valuable tool in evolutionary biology. It is easier to obtain good sequences from mitochondrial DNA than it is from chromosomal DNA (because there are multiple copies in each cell), it is inherited without recombination, and it accumulates mutations that are useful in phylogenetic analysis. You might ask, what is phylogenetic analysis and how are mutations used? Phylogenetic analysis simply means the study of evolutionary relationships among organisms. Mutations play a role in phylogenetic analysis because they are ideal "tags" for lines of descent. The presence of a particular mutation within a group of animals is evidence of a common ancestor. Most mutations are not passed down to subsequent generations, but some do become common within the population. A mutation that is present at a significant level (over 1%) within a population is often called a polymorphism.

How do mutations allow phylogenetic analysis? In this genomics science fair project, you will compare mitochondrial DNA from a woolly mammoth to mitochondrial DNA from a mastodon, an Asian elephant, and an African elephant. Based on the level of similarity, you will be able to determine how closely the mammoth is related to mastodons and to modern elephants.

As outlined in the Experimental Procedure, below, you will first download the sequence for woolly mammoth mitochondrial DNA. You will then use BLAST, a software tool available at the National Center for Biotechnology Information (NCBI) website, to search a database of DNA sequences for the best matches to the mammoth DNA. You will be using BLAST to infer evolutionary relationships among the modern elephants and their extinct relatives.

For the basic procedure, you will BLAST a portion of the woolly mammoth mitochondrial DNA against a small set of related sequences from mastodon and elephant sequences. Once you are familiar with the tools and databases, you can expand your science fair project to include protein sequences. You can also expand the number of organisms you search for with the BLAST tool.

Terms and Concepts

To start your background research, look up the terms below. Also, the paper by Rohland, et al., cited in the Bibliography, has very useful data and background information.

  • Paleobiologist
  • Woolly mammoth (Mammuthus primigenius)
  • Proboscidian
  • Asian elephant (Elephas maximus)
  • African elephant (Loxodonta africanus)
  • Mastodon (Mammut americanum)
  • Mitochondrial DNA (mtDNA)
  • Recombination
  • Phylogenetic analysis
  • Mutation
  • Polymorphism
  • BLAST
  • Genome
  • Molecular clock
  • Base pairs
  • Query

Questions

  • Based on the diagram in Figure 2, how long ago did the mastodons diverge from the elephants and mammoths?
  • How is mitochondrial DNA used to establish phylogenetic trees?
  • What is the relationship between the number of mutational differences in two mitochondrial genomes and the length of time since they diverged? In other words, how can you use mutations to establish a molecular clock?

Bibliography

Materials and Equipment

  • Computer with high-speed connection to the Internet
  • Lab notebook

Share your story with Science Buddies!

I did this project I Did This Project! Please log in and let us know how things went.

Experimental Procedure

First, obtain the sequence information for woolly mammoth mitochondrial DNA.

  1. To download the mitochondrial DNA sequence for woolly mammoth mitochondrial DNA, go to the National Center of Biotechnology Information's (NCBI) database of nucleotide sequences, at http://www.ncbi.nlm.nih.gov/sites/entrez?db=nucleotide.
  2. In the "Search" box, select "Genome" from the drop-down menu.
  3. In the "Search" box, type "Mammuthus primigenius mitochondrion, complete genome."
  4. You will retrieve a page with the search results. If there is more than one result, look for the one that has the accession number NC_007596. This number is a unique identifier for this record.
  5. Click on the link to the record for NC_007596. Under the "Genome Info" column, click the NC_007596 link in the first row, "Refseq."
  6. Scan up and down the page for NC_007596. It has a wealth of information, including the names of the researchers who submitted the sequence, the date of submission, the sequence of the proteins coded for by the mitochondrial DNA, and the complete mitochondrial DNA sequence (at the bottom of the page).

Now that you have the DNA, you can use it to search for similar sequences in a database of nucleotide sequences.

  1. Now open a new window or tab in your internet browser and go to the NCBI main page, and click on the BLAST link at the top of the page.
  2. This page has information about how BLAST works, as well as links to various BLAST search tools.

The page describes the BLAST search tools, as follows: "The Basic Local Alignment Search Tool (BLAST) finds regions of local similarity between sequences. The program compares nucleotide (or protein) sequences to sequence databases and calculates the statistical significance of matches. BLAST can be used to infer functional and evolutionary relationships between sequences, as well as help identify members of gene families."

  1. Click on the link for "nucleotide BLAST" under the "Basic BLAST" heading.
  2. Enter the accession number NC_007596 into the box labeled "Enter accession number, gi, or FASTA sequence,"
  3. In the boxes that indicate "From" and "To," type in "1" for "From" and "3000" for "To." The first 3000 base pairs will be used as the query. BLASTing the entire 16,770 nucleotides slows the BLAST results and is not necessary for our purposes.
  4. In the "Job Title" box, type "Woolly Mammoth," or another name if you choose.
  5. For "Database," click "Others (nr etc)."
  6. Select "Reference genomic sequences" in the drop-down box. This database has single copies (reference sequences) of the mitochondrial genomes for each species, which makes evolutionary analysis easier.
  7. For "Organism," type "Proboscidia (taxid:9779)." This will restrict your BLAST to the elephants and their extinct relatives. Be sure there is no space between the "taxid:" and "9779." Return to this point later if you want to BLAST against a wider array of sequences. Leave the "Entrez Query" field blank.
  8. For "Program Selection, Optimize for," select "Highly similar sequences, megablast." (The alternatives are more appropriate when searching for distant similarities). The page should look like the one below in Figure 3.

NCBI BLAST page
Figure 3. NCBI BLAST page. (NCBI, 2008.)

  1. Click on the BLAST button to start the database search.
  2. Be patient. The search algorithm will take about a minute or so to complete the database search. The results page will resemble the one below in Figure 4.
    1. When the BLAST results page appears, save it to your computer by clicking the "File" tab and then "Save page as." This will allow you to return to the results later, if needed.

BLAST results for woolly mammoth mitochondrial DNA
Figure 4. BLAST results for woolly mammoth mitochondrial DNA. (NCBI, 2008.)

  1. The BLAST results page has three parts: a color key of the alignments (top part of Figure 4), a table that lists hits in the database (lower part of Figure 4), and the actual BLAST alignments (not shown in Figure 4).
  2. The color key shows the degree of similarity for the sequences.
  3. Look at the data in the BLAST table. The "Query Coverage" notes how much of the query was aligned with the hit in the database—for this science fair project, this should be 100%. The "Max. ident." column gives the % identity between the woolly mammoth DNA and other members of the Probiscidae order.
    1. Based on these results, which animal is the woolly mammoth most closely related to?
  4. Scroll down the BLAST results page, and look at the alignments of the query and database sequences.
    1. The alignment is the heart of the BLAST output. It pairs each base in the query with its counterpart in the database sequence.
    2. Look for mismatches and gaps in the alignments to get an idea of the type of changes that occur.
  5. At the top of each alignment, there is information on the % identity and the number of mismatches between the query and the database sequence.
  6. Make a data table in your lab notebook of the actual number of changes between the mammoth DNA and the DNA of the other animals. For the woolly mammoth vs. the Asian elephant, for example, the data says: "Identities = 2940/3000 (98%), Gaps = 1/3000 (0%)". Thus, there are 60 changes (3000 - 2940).
  7. Using the approximate times that these animals diverged from each other (from the Introduction section, above), and the actual number of differences in the DNA, estimate the rate at which the mitochondrial DNA acquires mutations. See the example below.

Equation 1:

Mutation rate ~   Number of changes from BLAST report
Number of nucleotides × Number of years

Equation 2:

Mutation rate ~         60
3,000 × 6,700,000

  1. You can compare your result for the mutation rate with a published mutation rate in the paper by Nadin Rohland and his colleagues, found in the Bibliography, above. You'll want to look for the link to table S3, further down on the webpage. The rate you calculate will not be identical to the published rate, due to differences in the methods and DNA regions used.

Next, use the BLAST output to generate a phylogenetic tree of your results.

  1. On the BLAST output page, click on he link "Distance tree of results."
  2. To format as in Figure 5, click on the "Slanted" tab and use "taxonomic name" for "Sequence label." Try various formats.

BLAST results for woolly mammoth mitochondrial DNA
Figure 5. Tree of mammoth, mastodon, and modern elephant mitochondrial DNA. (NCBI, 2008.)

  1. Add times and mutations to the tree that you make. Discuss the degree of relatedness between the sequences, as shown in the tree.

Share your story with Science Buddies!

I did this project I Did This Project! Please log in and let us know how things went.


Variations

These variations suggest ways that you can extend your analysis of the woolly mammoth's mitochondrial genome.

  • In the main Experimental Procedure above, you used a region of mitochondrial DNA to establish the family structure of the Proboscidea. Extend this analysis using mitochondrial proteins. Retrieve the record from NCBI for nucleotide sequence NC_007596. Copy a protein sequence, for example for the protein "NADH dehydrogenase subunit 1," from the NCBI page for NC_007596. Enter the sequence in the BLAST page, clicking this time on "Protein BLAST." Enter the other settings, as you did for the DNA BLAST. Compare the results of your protein BLAST vs. the eDNA BLAST.
  • In the paper by Rohland, referenced in the Bibliography, they excluded the D-loop region of the mitochondrial DNA because it accumulates mutations at a faster rate than the rest of the genome. Repeat the analysis with the D-loop excluded (the NCBI page for NC_007596 indicates the D-loop boundaries).
  • Extend the number of organisms that you are comparing with the mammoth. You can do this by selecting a larger set of animals in the "Organisms" box. (Mammoths are classed as follows: Eukaryota, Metazoa, Chordata, Craniata, Vertebrata, Euteleostomi, Mammalia, Eutheria, Afrotheria, Proboscidea).
  • Download the DNA or protein sequences from the BLAST results and generate a tree using the tools at the European Bioinformatics Institute.
  • Repeat this analysis with a set of primate genomes. As noted in the paper by Rohland, the rate at which mutations accumulate in the primate line is dramatically different than it is in the elephant line. The reason is unknown.
