What Causes Lightning?

Summary

Grade Range
6th-8th
Group Size
2-3 students
Active Time
60 minutes
Total Time
60 minutes
Area of Science
Physics
Key Concepts
Static electricity, electric fields, electric charges, triboelectric effect
Credits
Svenja Lohner, PhD, Science Buddies Alumni
Video narration by Jennifer E Paz
Pricing
Free for a limited time thanks to individual donors
Video Lesson
Joseph Wright of Derby, A Philosopher Giving A Lecture at the Orrery, c. 1765, oil on canvas, 147 x 203 cm (Derby Museum and Art Gallery, Derby, England)
Get Student Link

Overview

Lightning is a powerful display of static electricity in nature. But what is static electricity? In this lesson, students will learn about static electricity and electric fields by building a device that can detect electrical charges, called an electroscope. They will use their electroscope to investigate how well different materials can build up electric charges by rubbing them against wool. During their experiments, students will be able to demonstrate how electric fields exert forces on objects close by.

Learning Objectives

Materials

Per group:

Per student:

Prep Work

  • Print out a worksheet for each student.
  • Select additional materials you want the students to test. Possible materials are wood, other plastic objects, glass, or rubber.
  • If you bought a spool of copper or brass wire, cut the wire into 12-inch pieces. One piece for each student group.
  • Note: This experiment works best in a dry environment. If it is too humid, the experiment won't work as well. Humidity in the air makes the air more conductive and able to absorb excess charges. As a result, objects won't hold static charges well in a humid environment. An ideal relative humidity for electrostatic buildup is below 40 percent. Between 40 and 60 percent, a charge buildup is still possible but at a significantly reduced level.

Engage (11 minutes)

In this video, students wonder about the nature of lightning and are introduced to static electricity and electric fields by looking into Benjamin Franklin's famous kite experiment.

Explore (44 minutes)

In this video, students will be guided through building an electroscope and using it to detect static electricity in various objects. As they experiment with electric charges, they will not only learn how an electroscope works but will also observe how electric fields can push and pull on objects in their surroundings.

Reflect (5 minutes)

This video will provide students with an answer to the lesson's guiding question, "What Causes lightning" as it explains how static electricity and lightning are connected.

NGSS Alignment

This lesson helps students prepare for these Next Generation Science Standards Performance Expectations:
  • MS-PS2-5. Conduct an investigation and evaluated the experimental design to provide evidence that fields exist between objects exerting forces on each other even though the objects are not in contact.
This lesson focuses on these aspects of NGSS Three Dimensional Learning:

Science & Engineering Practices
Planning and Carrying out Investigations. Planning and carrying out investigations to answer questions or test solutions to problems in 6-8 builds on K-5 experiences and progresses to include investigations that use multiple variables and provide evidence to support explanations or design solutions.

Conduct an investigation and evaluate the experimental design to produce data to serve as the basis for evidence that can meet the goals of the investigation.
Disciplinary Core Ideas
PS2.B: Types of Interactions. Forces that act at a distance (electric, magnetic, and gravitational) can be explained by fields that extend through space and can be mapped by their effect on a test object (a charged object, or a ball, respectively).
Crosscutting Concepts
Cause and Effect. Cause and effect relationships may be used to predict phenomena in natural or designed systems.

Assess

The student worksheet can be used to evaluate students' understanding of the activity and basic concepts.
