Porosity and Particle Size

Introduction

Have you ever heard the expression, "solid as a rock"? As it turns out, rocks are not entirely solid. Rocks actually have tiny pockets of air inside them. This is obvious when you look at a piece of volcanic rock (often called basalt), which is full of visible holes. But dense rocks, such as granite, have tiny air pockets inside them, too. These pockets of air are just much smaller.

If you picked up one volcanic rock as well as one granite rock of the same size, you would notice they don't weigh the same. The granite is heavier than the volcanic rock. The many large holes of air in the latter make it less dense—and more porous—than the granite, which also makes it lighter. Something that has more holes in it is more porous. So "porosity" is one characteristic that can help tell you what kind of rock you have.

Background

Rocks—and most other objects, for that matter—are made up of particles of varying sizes that are packed together. In between the particles are spaces that are filled with gas, air or liquid. Particles' shapes and sizes affect how they aggregate, including how tightly they can pack together, which affects a rock's porosity—a property that is the ratio of the volume of a rock's empty spaces to its total volume.

In general, larger particles cannot pack together as well as smaller particles can, which means that packing larger particles together leaves more space for air to fill between the particles. You can imagine this if you have one cup full of marbles and another cup full of sand. You'll be able to see many more spaces between the marbles than between the grains of sand.

Materials

• Three clear plastic cups
• Water
• Measuring cup
• Rocks that can be sorted into one of three size groups (ideally all of the same type of rock, such as granite)
• Screen (optional)

Observations and Results

Could you see the spaces between the rocks in the cups? Did the cup with the largest rocks have more air than the cup with the smallest rocks? Did the cup with the smallest rocks have less air than the cup with the medium-size rocks?

This activity modeled the inside of rocks on a much larger scale. Because, in general, larger particles cannot pack together as tightly as smaller particles can, a rock made out of larger particles will usually be more porous than a rock made out of smaller particles. But rocks are not static; like everything, rocks change over time. When enough pressure, or force, is applied to a rock, the pressure can make the rock more efficiently pack its particles. Usually pressure builds up on rock over a long period of time, as dirt and other rocks end up on top of it. You can see how this process, known as compaction, makes the rock's porosity decrease with time.
