Rubbing Up Against Static Electricity
|Time Required||Very Short (≤ 1 day)|
|Material Availability||Readily available|
|Cost||Very Low (under $20)|
AbstractA tried and true balloon activity is to rub a balloon on your head to make your hair stand up. How does the rubbing build up static electricity? Do this experiment to see if the number of rubs makes a difference.
Test if the number of rubs of wool on a balloon increases or decreases how long the static charge will last.
Sara Agee, Ph.D., Science Buddies
Cite This Page
Last edit date: 2017-07-28
Static electricity is the build-up of electrical charge in an object. Sometimes static electricity can suddenly discharge, like when a bolt of lightning flashes through the sky. Other times, static electricity can cause objects to cling to each other, like socks fresh out of the dryer. The static cling is an attraction between two objects with different charges, positive (+) and negative (–).
You can create static electricity by rubbing one object against another object. This is because the rubbing releases negative charges, called electrons, that build up to produce a static charge. For example, when you shuffle your feet across a carpet, you are making many small contacts between the surface of your feet and the carpet, allowing electrons to transfer to you, building up a static charge on your skin. You can suddenly discharge this static charge as a shock when you touch a friend or some objects. Similarly, when you rub a balloon on your head it causes opposite static charges to build up in your hair and in the balloon. You can see these two opposite static charges attracting each other when you pull the balloon slowly away from your head making your hair stand up, as shown in Figure 1, below. You can learn more about electric charges and static electricity in the Science Buddies Electricity, Magnetism, & Electromagnetism Tutorial.
Figure 1. Static electricity makes your hair stand up! (NASA, 2004)
In this experiment you will test if the number of rubs can change how long the static charge will last by rubbing a balloon with wool and timing how long it will cling to a wall. Wool is a material that readily donates its electrons, so when you rub the balloon with it it will donate its electrons to the surface of the balloon, giving part of the balloon a negative charge. The wall should normally have a neutral charge, but the charges within it can rearrange so that a positively charged area is interacting with the negatively charged balloon, causing the balloon to stick to it. By doing this experiment you can investigate how effective rubbing wool against a balloon is at creating static electricity and a static charge.
Terms and Concepts
- Static electricity
- Static charge
- How does friction produce static electricity?
- How is static electricity related to charge?
- How can you measure static electricity?
- Science Made Simple. (n.d.). Static Electricity: What Causes Static Shocks? Retrieved March 18, 2006 from http://www.sciencemadesimple.com/static.html
- Museum of Science, Boston. (n.d.). Static Electricity: Electricity Medley. Retrieved June 19, 2014, from http://www.mos.org/sites/dev-elvis.mos.org/files/docs/education/mos_observing-electricity-magnets_electricity-medley.pdf
- The Library of Congress. (2011, June 1). How does static electricity work? Everyday Mysteries. Retrieved June 19, 2014, from http://www.loc.gov/rr/scitech/mysteries/static.html
- Brynie, F.H., 2005. Parents Crash Course: Elementary School Science Fair Projects, Hoboken, NJ: Wiley Publishing Inc. pp 124-130.
For help creating graphs, try this website:
- National Center for Education Statistics, (n.d.). Create a Graph. Retrieved June 2, 2009, from http://nces.ed.gov/nceskids/createagraph/
News Feed on This Topic
Materials and Equipment
- Balloons (at least 3). Smaller balloons, like water balloons, may work better in humid environments, but you will still blow the balloons up with air.
- Woolly sweater, scarf, or blanket
- Lab notebook
Remember Your Display Board Supplies
Poster Making Kit
ArtSkills Trifold with Header
- For this experiment, you will need a data table for your results. You will need one data table for each trial, so make at least three data tables for doing at least three separate trials. You can use a data table like Table 1.
|Number of Rubs||Stays on Wall? (Y/N)||Time on Wall (seconds)|
- Blow up the balloon and tie off the end.
- Rub the balloon on the scarf once, in one direction.
- Hold the balloon up on the wall, start the stop watch and release. Does it stay on the wall? If not, stop your stop watch and write "0 seconds" in your data table.
- Touch the balloon to a metal object. This should discharge any extra electrons into the metal.
- Repeat steps 3 to 5, increasing the number of rubs each time until the balloon sticks to the wall. When you increase the number of rubs do not rub the balloon back and forth, but instead always rub the balloon in the same direction each time.
- When the balloon does stick to the wall, keep the stop watch going until the balloon falls off of the wall. When it does, stop the stop watch and write the time in the data table next to the matching number of rubs.
- Repeat step 7, increasing the number of rubs each time and recording the amount of time the balloon sticks to the wall with the stop watch. Write the results in the data table each time. You can continue increasing the number of rubs until you have several data points for the balloon sticking to the wall.
- Make a graph of your results. You can make your graph by hand or you could use a program like Create a Graph to make it on a computer and print it out. A line graph is the best type of graph for this experiment. Make a scale on the left side of the graph (Y-axis) for the time in seconds, and a scale on the bottom of the graph (X-axis) for the number of robots. For each point of data, make a dot where the number of rubs and the time in seconds intersect.
- Analyze your results. Does your data make a line? Does the line go up or down? Does the line level off at some point, or keep going? Does the time the balloon stays on the wall increase or decrease with the number of rubs?
- Repeat steps 2–10 at least two more times so you have done a total of at least three trials total. Does the data for each trial match with the previous trials?
Communicating Your Results: Start Planning Your Display BoardCreate an award-winning display board with tips and design ideas from the experts at ArtSkills.
If you like this project, you might enjoy exploring these related careers:
PhysicistPhysicists have a big goal in mind—to understand the nature of the entire universe and everything in it! To reach that goal, they observe and measure natural events seen on Earth and in the universe, and then develop theories, using mathematics, to explain why those phenomena occur. Physicists take on the challenge of explaining events that happen on the grandest scale imaginable to those that happen at the level of the smallest atomic particles. Their theories are then applied to human-scale projects to bring people new technologies, like computers, lasers, and fusion energy. Read more
Materials Scientist and EngineerWhat makes it possible to create high-technology objects like computers and sports gear? It's the materials inside those products. Materials scientists and engineers develop materials, like metals, ceramics, polymers, and composites, that other engineers need for their designs. Materials scientists and engineers think atomically (meaning they understand things at the nanoscale level), but they design microscopically (at the level of a microscope), and their materials are used macroscopically (at the level the eye can see). From heat shields in space, prosthetic limbs, semiconductors, and sunscreens to snowboards, race cars, hard drives, and baking dishes, materials scientists and engineers make the materials that make life better. Read more
- Does rubbing in one direction give a different result than rubbing back and forth? Try a different experiment comparing the same number of rubs in one direction compared to back and forth. Does one stay up on the wall longer than the other?
- Static electricity is not good when it gets in your clothes! How do dryer sheets work? Try an experiment rubbing the balloon with a dryer sheet (like Bounce) after rubbing against the wool. What happens to the static cling? Can you rub different times, measure the results and make a graph? If you can, you can make a graph to compare the results of different products. How do they compare? Do they take the same number of rubs to reduce the static cling? Which brands are most effective?
- Try comparing the effectiveness of different materials for producing a static charge. Does rubbing wool work better than rubbing silk? Design an experiment to test several different materials: silk, wool, nylon, polyester, plastic, metal, etc.
- For a more advanced experiment, try investigating static electricity in different conditions, temperatures and humidities (Brynie, 2005).
