How Sweet It Is! Measuring Glucose in Your Food

1
2
3
4
5
876 reviews

Abstract

You know that sugar makes food sweet, but did you know that there are different kinds of sugar? Sucrose is the granulated sugar that you usually use for baking. Another kind of sugar, which is found in honey and in many fruits, is glucose. In this science project, you will measure the concentration of glucose in a variety of foods. You will use special test strips that change color in response to glucose to measure the glucose concentration in different foods.

Summary

Areas of Science
Difficulty

Time Required
Very Short (≤ 1 day)
Prerequisites
None
Material Availability
A Sugar Metabolism Kit containing most of the specialty supplies needed for this project is available from our partner Home Science Tools.
Cost
Average ($40 - $80)
Safety
No issues
Credits

David Whyte, PhD, Science Buddies

Recommended Project Supplies

Get the right supplies — selected and tested to work with this project.

View Kit

Objective

To measure the concentration of glucose in a variety of common fruits and juices.

Introduction

Fresh pineapple, chilled watermelon, and an icy cold soft drink on a hot summer's day. What do these things have in common? They all taste so good because of the sweetness the sugar in them provides. When you think of sugar, you probably picture the white granules you put in cookies, that your parents put in their coffee, or that you put on your cereal. Actually, this is just one kind of sugar, called sucrose, shown in Figure 1 on the right, which is extracted from sugar cane or sugar beets. Technically, sugar is a carbohydrate that occurs naturally in every fruit and vegetable. It is the major product of photosynthesis, the process by which plants transform the Sun's energy into food.

Glucose is another type of sugar and is a very important biochemical. For one thing, glucose is the only fuel used by brain cells. Glucose is also an important source of energy for muscles and other tissues in the body.

The glucose in your blood comes from the food you eat. Complex carbohydrates, found in pasta or cereal, for example, are long chains of sugar molecules that are broken down by enzymes to simple sugars, such as glucose. Sucrose, or table sugar, is also broken down to form glucose. Because carbohydrates and sucrose in food are broken down to form glucose, the level of glucose in your blood goes up after you eat.

A honey wand in a bowl of honey   four difference sucrose sugars
Figure 1. Sugars can come in various forms such as glucose and fructose, which are the main sugars in honey (left), or sucrose, which is the sugar we most commonly use (right).
(Image credit: by Lama Raheem (honey) and by Romain Behar (sucrose), via Wikimedia Commons)

Like most of the chemicals in your blood, the level of glucose must be tightly controlled. The level of glucose in your blood is controlled by insulin, a hormone made in the pancreas. People with diabetes, a serious health problem in the United States, have bodies which are unable to regulate blood sugar levels either because their bodies do not make insulin (type 1 diabetes) or their bodies do not respond to insulin (type 2 diabetes). Too little glucose, and your brain and other organs will not have the energy they need to function. Too much glucose over a long period of time damages blood vessels carrying blood to major organs and can lead to heart disease and strokes along with kidney, nerve, and vision damage. To avoid those problems, diabetics carefully monitor their blood glucose level and make adjustments to insulin or diet, as needed, to maintain a healthy blood glucose level.

In this science fair project, you will investigate the concentration of glucose in common fruits and juices. In order to measure the glucose concentration, you will use glucose test strips. These strips were developed to help people with diabetes maintain a healthy level of blood glucose. When you dip the test strip into a liquid, such as orange juice, it changes color if glucose is present. The degree of color change depends on the concentration of glucose.

Terms and Concepts

Questions

Bibliography

Materials and Equipment Buy Kit

Recommended Project Supplies

Get the right supplies — selected and tested to work with this project.

View Kit

These specialty items can be purchased from our partner Home Science Tools:

You will also need to gather these items (not included in the kit):

Disclaimer: Science Buddies participates in affiliate programs with Home Science Tools, Amazon.com, Carolina Biological, and Jameco Electronics. Proceeds from the affiliate programs help support Science Buddies, a 501(c)(3) public charity, and keep our resources free for everyone. Our top priority is student learning. If you have any comments (positive or negative) related to purchases you've made for science projects from recommendations on our site, please let us know. Write to us at scibuddy@sciencebuddies.org.

Experimental Procedure

  1. To start this science fair project, you should first collect all of the foods and juices that you plan to test.
  2. Based on your research, predict which foods will have the highest glucose levels. List the foods in your lab notebook in order from highest to lowest predicted glucose concentration.
    1. One place to start your research is www.nutritiondata.com, which reports glucose levels for some raw ingredients (nuts, fruits, vegetables, etc). To get to that information, search for the ingredient, scroll down to "Nutrition Information" and click the "More details" tab under "Carbohydrates". Remember that for processed food, the labels on most products list total sugar, which is a mixture of several sugars such as sucrose, fructose, lactose, maltose, galactose and glucose. The test strip only measures glucose concentration.

Making the Positive and Negative Controls

Controls are samples with known ingredients that should give clear, expected results. They are used to test the procedure. Using a positive control, there should be a clear "signal," or color change, showing that the glucose strips are working properly. Using a negative control, there should be no "signal," or color change. Tap water is a suitable negative control (because it has no glucose).

  1. First, make the positive controls using water and the glucose powder. To do this, make a dilution series using sequential twofold dilutions to create the following concentrations: 2%, 1%, 0.5%, 0.25%, 0.125%, and 0.0625%.
    1. Label six cups: 2%, 1%, 0.5%, 0.25%, 0.125%, and 0.0625%.
    2. Add 4 grams (g) of glucose to 200 mL of water in the cup labeled 2% and stir until the glucose dissolves.
    3. Optional: Add 2–5 drops of food coloring to the 2% glucose solution. The color does not matter. Note: The food coloring will allow you to keep track of your dilution levels as the color of each dilution will get less intense. It does not interfere with the glucose measurements.
    4. Add 100 mL of water to the other five cups.
    5. Measure 100 mL of the 2% solution and add it to the 100 mL of water in the cup labeled 1% to make 200 mL of 1% solution. Stir well.
    6. Measure 100 mL of the 1% solution and add it to the 100 mL of water in the cup labeled 0.5% to make 200 mL of 0.5% solution. Stir well.
      1. Between each dilution, make sure to rinse and shake the excess water from the graduated cylinder or container you are using to transfer the 100 mL volumes. Also, use a clean stirrer.
    7. Repeat this process for the remaining dilutions.
      1. When you are done, each cup should have 100 mL of liquid, except for the 0.0625% solution, which should have 200 mL.
  2. Fill an extra cup with 100 mL water. Do not add any of the glucose solutions to it. Label it 0%. This will be your negative control.
  3. If you used food coloring for your dilution series, you should now have seven cups that look similar to the ones in Figure 2.
Seven plastic cups filled with a red liquid of decreasing concentrations
Figure 2. If you used food coloring (in this picture, red food coloring was used), the glucose dilution series should look like the ones in this picture (arranged by most concentrated to least, from left to right). (Each cup should have 100 mL of liquid, except for the 0.0625% solution, which should have 200 mL.) A seventh cup, serving as the negative control, should only contain water (on the far right in this picture).
  1. Dip a test strip into the solution in the cup labeled 2%. After 1–2 seconds, remove the test strips from the solution. Tap the test strip on the rim of the cup to remove excess solution and watch it for 30 seconds (which should be the time recommended in the test strip instructions). Then match the color of the glucose marker on the test strip to the color on the bottle shown in Figure 3. Does the color match what you would expect? Write down your observations in your lab notebook. Note: For high glucose concentrations, it might take up to 60 seconds until the color matches the actual concentration.
    1. See the Technical Note: Reading Glucose Test Strips for guidance on matching the color of the glucose test strips to the color on the bottle.
    2. If the color changes to the maximum range (2%) before 30 seconds, list it as greater than 2% (">2%").
  2. Repeat step 4 for each of the six other cups.
    1. If you do not have a clear color change for any of the positive control solutions with a concentration greater than 0.0625%, repeat the procedure. If the second time it is still problematic, re-read the instructions for steps 3 and 4 to make sure you have made the dilutions properly and are handling the strips according to the instructions.
    2. It is ok to have a slightly lower reading for the pure glucose solutions. Remember, these test strips were designed for measuring low concentrations of glucose in a urine sample so the results might be slightly different for pure glucose solutions. If the test strips for the glucose solutions at 30 seconds are more than one color off from what it is expected to be (for example, if the 1% solution reads less than 0.5% or the 0.25% solution reads greater than 0.5%), you could adjust the readout time accordingly (for example to 60 seconds). However, you have to make sure, that throughout the experiment, you keep the same readout time for all of your samples.
Technical Note: Reading Glucose Test Strips

When matching the color of a glucose test strip to a color on the bottle, keep in mind these helpful tips:

  • The colors on the bottle will not exactly correspond to the percent glucose solutions you made. There will probably be colors for 0% ("Negative"), 0.1%, 0.25%, 0.5%, 1% and 2% glucose solutions, as shown in Figure 3.
  • Some test strip colors may fall between two of the colors on the bottle, for example between 0.5% and 1%. If this happens, write down the two numbers in your lab notebook and calculate their average.
  • If the color changes to the maximum range (2%) before 30 seconds, list it as greater than 2% (">2%"). If this happens in the Experimental Procedure, you may need to then perform a dilution and re-test the sample. You will get more accurate results if you start diluting your samples once the glucose concentration is getting close to 1%.
Technical Note: Dilutions

When testing solutions, you might need to dilute your sample to get a more accurate reading.

Use a 1:10 dilution when you expect the sample to have a very high glucose concentration (e.g. non-diet soft drinks) or are viscous (e.g., peanut butter, honey, or molasses).

There are two ways in which you may perform a 1:10 dilution, and the preferred way will be specified in the text:

  • Use a transfer pipette to add 9 drops of water and 1 drop of the test solution on a bottle cap. Rinse the transfer pipette in between each sample.
  • Mix 1/2 teaspoon (tsp.) (2.5 mL) of the sample with 22.5 mL water to make a 1:10 dilution.

Remember that if the 1:10 dilution reading reports 1% glucose, then the glucose in the sample is 10%, because it was diluted tenfold.

Use a 1:4 dilution when glucose readings are close to 2% to get a more accurate glucose concentration reading.

You may perform a 1:4 dilution by adding 30 mL of water to 10 mL of your solution. Stir well. Label the cup 1:4 dilution of the sample. Remember that if the 1:4 dilution reading reports 1% glucose, the glucose in the sample is 4%, because it was diluted fourfold.

Occasionally, you might have to dilute a 1:10 dilution further to obtain an accurate measurement. When diluting a 1:10 dilution two-fold, you obtain a 1:20 dilution. You can do this by adding 10 mL of water to 10 mL of 1:10 diluted solution. Multiply the measurement of the 1:20 diluted sample by 20 to obtain the glucose concentration level of the undiluted sample.

Technical Note: Dilutions and Measurement Accuracy

Diluting the sample tenfold to create a sample with a glucose concentration that can be measured with the glucose test strips allows you to measure higher concentrations. Unfortunately, these measurements will be less accurate. Because the measured concentration from the diluted sample gets multiplied by 10 to obtain the concentration of the original sample, any inaccuracy in the measurement will also be multiplied by 10. Because of these inaccuracies, high glucose concentrations measured using a ten-fold dilution will give you an idea of the glucose concentration but not an accurate measurement.

Color chart for glucose test strips has six squares of varying color starting at a light blue for 0% and a dark brown for 2%
Figure 3. This is the color chart for glucose on the test strip bottle. After a glucose test strip is dipped in a glucose solution and removed, its color should change and match a color on its bottle (or be between two colors). The color on the bottle will indicate the percentage of glucose in the solution tested.

Testing the Foods for Glucose Concentration

  1. Pour a small amount of liquid that you plan to test into a cup.
  2. Get ready to start the stopwatch.
  3. Dip the test strip into the liquid.
    1. For the fresh fruits and vegetables, press the test strip against a freshly cut slice until the test strip is thoroughly wet.
    2. For very high-glucose liquids, such as honey or soft drinks (not diet), or viscous substances, such as peanut butter, molasses, or baby food, dilute the samples in water prior to testing as described in the third bullet point of the Technical Note: Dilutions. For example, mixing 2.5 mL (0.5 teaspoon [tsp]) of honey with 22.5 mL (4.5 tsp.) water makes a 1-to-10 dilution. Remember to multiply the concentration of glucose in the diluted solution by 10 to obtain the concentration of glucose in the original sample.
  4. After 1–2 seconds, remove the test strip from the liquid or food, tap it on the rim of the cup to remove excess liquid, and immediately start the stopwatch.
  5. Wait for the amount of time specified on the test strip directions, usually 30 seconds, or the reaction time you established while testing the positive controls.
  6. Compare the color on the test strip with the color on the side of the container to determine the glucose concentration.
    1. If the color changes to the maximum range (2%) before 30 seconds, list it as greater than 2% (">2%").
    2. To determine the actual percent of glucose in samples with over 2 percent, dilute the sample as described in the Technical Note: Dilutions to bring the glucose level down within the range of the test strips. You will get more accurate results if you start diluting your samples once the glucose concentration is getting close to 1%.
    3. Test the diluted sample. Remember to adjust the measured glucose concentration to obtain the glucose concentration of the undiluted sample.
  7. Repeat steps 1–6, of this section, for all of your foods and juices.
  8. Make a data table of your results in your lab notebook. Table 1 is an example, with a "predicted" column for what you expected to find, and an "experimental" column for your actual results.
  9. Use < 0.5% for "low," 1%–2% for "medium," and >2% for "high."
  10. Repeat the glucose measurements for at least three trials (three samples of each type of food). Calculate the average glucose concentration for this type of food by averaging the measurements of all trials for this type of food.
  11. Graph your results. Put the type of food on the x-axis and the average glucose concentration on the y-axis.
  12. Did your results match your predictions? Were some foods surprising in the amount of glucose they contained?
Type of Food Glucose Level: Predicted Glucose Level: Experimental Notes
Mixed fruit drink High 10% (1% in diluted sample) Diluted 1:10 (example)
Orange juice Low 1% Tropicana

Table 1. In your lab notebook, make a data table like this one to record your results in.
